This article describes how to use the memleak tool to find memory leaks.

Overview

To debug memory leaks, the memleak tool from the bcc-tools suite can be very useful. It does not require to change the application like a lot of heap profilers require. If the bcc-tools are not yet installed, they can be installed on arch linux with

1

pacman -S bcc-tools

The program also requires the linux-headers package. If the package is not yet installed, it can be installed with the following command:

1

pacman -S linux-headers

Signs of memory leaks

Monitoring the RSS size and the virtual size of a process over time might give good hints if there is a potential memory leak. If the virtual size grows continuously at a faster pace as RSS, there is a high likelyhood that there is a memory leak. Another indiciation is if the memory size of the process does not stabilize and continues to grow.

Invoking the tool

The memleak tool can be invoked with the -c switch to start the to be analyzed program at the same time as the memleak tool. The other way is to attach the memleak tool with the -p switch to a running process.

Monitoring individual memory allocations

With the -t switch individual allocations and de-allocations can be monitored. This is very useful to see how much memory is allocated. These are the memory allocations that are performed by the kernel on behalf of the process. The user space memory manager of the process might process a lot more memory allocation and memory de-allocation requests. The memleak tool does not report the user-space requests.

The tool can be invoked with:

1

sudo memleak -tp 11748

The -t flags specifies tracing of individual allocations and the -p flag specifies which process to trace.

The following gives an impression of the typical output:

1
2
3
4
5

(b'top', 11748, 8, b'...11', 3393.638436, b'alloc entered, size = 7')
(b'top', 11748, 8, b'...11', 3393.638438, b'alloc exited, size = 7, result = 56140ebca620')
(b'top', 11748, 8, b'...11', 3393.638444, b'free entered, address = 56140ebc92b0, size = 7')
(b'top', 11748, 8, b'...11', 3393.63845, b'alloc entered, size = 5')
(b'top', 11748, 8, b'...11', 3393.638453, b'alloc exited, size = 5, result = 56140ebc92b0')

The format of the output is: task, pid, cpu#, flags, timestamp and allocation / de-allocation message. For each allocation it shows the two lines: alloc entered and alloc exited. For the de-allocation operation it only shows the free entered entry. For the allocations as well as for the de-allocation it reports the address as well as the size of the request. This makes it very easy to write scripts on top of the output to see which memory addresses do not get freed.

In addition it also shows the process id and the name of the process. If the process starts new threads or child processes they are also traced.

This has already helped to find some memory leaks in server applications.

Capturing call stacks

If the user specifies the -a option, the tool also captures the top call stacks of the callers. Typical result is something like this:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33

addr = 560cdc84a080 size = 29
addr = 560cdc846610 size = 29
addr = 560cdc848260 size = 29
addr = 560cdc849a00 size = 30
addr = 560cdc847e10 size = 32
addr = 560cdc846820 size = 32
30 bytes in 1 allocations from stack
0x00007fc75f6a33ef      __strdup+0x1f [libc.so.6]
0x622d36313a383475      [unknown]
32 bytes in 4 allocations from stack
0x00007fc75f6a33ef      __strdup+0x1f [libc.so.6]
0x0000746174732f35      [unknown]
32 bytes in 2 allocations from stack
0x00007fc75f6a33ef      __strdup+0x1f [libc.so.6]
0x00726f702d706f74      [unknown]
32 bytes in 2 allocations from stack
0x00007fc75f6a33ef      __strdup+0x1f [libc.so.6]
0x0064617068736172      [unknown]
32 bytes in 1 allocations from stack
0x00007fc75f6a33ef      __strdup+0x1f [libc.so.6]
0x74622d353a383475      [unknown]
32 bytes in 1 allocations from stack
0x00007fc75f6a33ef      __strdup+0x1f [libc.so.6]
0x74622d323a383475      [unknown]
45 bytes in 3 allocations from stack
0x00007fc75f6a33ef      __strdup+0x1f [libc.so.6]
0x0000767264726561      [unknown]
54 bytes in 7 allocations from stack
0x00007fc75f6a33ef      __strdup+0x1f [libc.so.6]
0x000000746174732f      [unknown]
63 bytes in 7 allocations from stack
0x00007fc75f6a33ef      __strdup+0x1f [libc.so.6]
0x0000746174732f00      [unknown]

Once potential leaks have been identified, this makes it easier to identify what code is reponsible for the allocation or de-allocation. There are additional flags to the memleak tool, which allow to report only allocations / de-allocations of a certain size.
